Conductor: Bare copper multi-strand wire in accordance with DIN VDE0812
Insulation: PFL/MD in accordance with DIN VDE0819
Color Code: Colored
Core Structure: Layered or paired
Shielding: Core/paired core with tin-plated braid
Jacket: PETP foil
Core Structure: Core/paired core twisted pair layered structure
Jacket: PETP foil
Shielding: Tin-plated copper braided sheath
Outer Jacket Material: PVC, TM2 in accordance with DIN VDE+HD21.1
Outer Jacket Color: Grey (RAL7000)
Technical Parameters
Maximum Operating Voltage: Up to 350/500V
Test Voltage U: 2000V
Minimum Bending Radius
Fixed Installation: 5xD
Mobile Installation: 10xD
Continuous Motion: 2xD
Operating Temperature
Fixed Installation: -30°C to +70°C
Mobile Installation: -5°C to +70°C
Oil Resistance: Resistant to light oils, gear oils, lubricating oils, etc.
Chemical Resistance: Refer to chemical resistance appendix table
Characteristics and Compliance
Characteristics: ◆ Extremely flexible ◆ Oil resistance ◆ Ultra-long service life ◆ Low-temperature flexibility ◆ Excellent electromagnetic performance ◆ Suitable for decomposers and shaft angle encoders
Compliance Certification:
Typical Applications
Suitable for high flexibility in applications such as speedometers, brakes, motor temperature control, and flexible mobile connection cables. Widely used in automation technology, control and production processes, woodworking machinery, construction of robots and industrial factories, meeting the high machinery demands even in dry, humid, severely humid, and low-temperature environments. Flexible connection cables.
