Structure: Hexagonal nut with a single slot (castle nut) or multiple slots (hex slotted nut) cut through one face.
-
Locking Mechanism: After tightening, a cotter pin is inserted through the slot(s) and a hole in the bolt, preventing the nut from rotating relative to the bolt.
-
Reusability: Can be reused as long as the nut and cotter pin are not damaged or deformed.
-
Technical Specifications
Nominal Size (d) |
Pitch (P) |
s (max) |
h (max) |
m (min) |
M3 |
0.5 |
5.5 |
6.0 |
2.4 |
M4 |
0.7 |
7.0 |
7.5 |
3.2 |
M5 |
0.8 |
8.0 |
8.2 |
4.7 |
M6 |
1.0 |
10.0 |
10.0 |
5.2 |
M8 |
1.25 |
13.0 |
13.0 |
6.8 |
M10 |
1.5 |
16.0 |
16.0 |
8.4 |
M12 |
1.75 |
18.0 |
18.0 |
10.8 |
M16 |
2.0 |
24.0 |
24.0 |
14.8 |
M20 |
2.5 |
30.0 |
30.0 |
18.0 |
