H05V-U

Product Structure:
Conductor: Single or stranded copper or tinned copper wires in accordance with IEC60228 VDE 0295 Class 5 standard.
Insulation: PVC/T11 in compliance with DNVDE 0281 Part 1 + HD21.1.
Color Code: Core colors as per HD402 standard for easy identification.

Standards and Approvals:
HD 213 S3, VDE-0281 Part-3, CE Low Voltage Directive, 73/23/EEC and 93/68/EEC.

Technical Specifications:
Rated Voltage: 300V/500V.
Test Voltage: 4000V in accordance with DIN VDE 0281 Part 2 + HD21.2.
Minimum Bending Radius:

Fixed installation: 12.5xD (cable outer diameter).
Mobile installation: 12.5xD (cable outer diameter).
Temperature Range:
Fixed installation: -30°C to +80°C.
Mobile installation: -5°C to +70°C.
Flame Retardancy: Compliant with IEC60332-1-2 + EN60332-1-2 ULVW-1 + CSA FT1.
Insulation Resistance: 10MQ x km.
Characteristics and Compliance:
Characteristics: Solid or stranded single-core wires, easy to strip, cut, and install. Compliant with European Union harmonized standards.
Certification: RoHS (EU Directive 2011/65/EU) compliant.

Typical Applications:
H05V-U wires are used for internal peripheral hardwiring between distribution panels and power distribution boards in electrical and electronic equipment. They are also suitable for interfaces between power supplies and lighting systems. The cables can be installed in exposed or embedded conduits.
