Conductor: Bare copper stranded wire, compliant with IEC 60228, EN 60228, VDE 0295, Class 5.
Insulation: PVC, TI2, compliant with DIN VDE 0281+HD 21.1.
Sheath Color: Black (RAL 9005).
Technical Parameters
Rated Voltage DIN VDE: Uo/U 300/500V.
H05V-K: UL/CSA: 600V.
Rated Voltage DIN VDE: Uo/U 450/750V.
H07V-K: UL/CSA: 600V.
Test Voltage
H05V-K: 2000V, compliant with DIN VDE 0281+HD 21.1.
Minimum Bending Radius: 4xD.
Temperature Range: DIN VDE UL-AWM/CSA (UL) MTW
Fixed installation: -40°C to +70°C, reaching +105°C.
Mobile installation: +5°C to +70°C, reaching +105°C.
Flame Resistance: Flame-retardant and self-extinguishing, compliant with IEC 60332-1-2+EN 60332-1-2, UL VW1, CSA FT1.
Characteristics and Compliance
Characteristics: ◆Flexible single-core wire ◆Compliant with European unified standards ◆MTW (Machine Tool Wire) ◆TEW (Thermoplastic Equipment Wire)
Compliance Certification:
Typical Applications
PUR connecting cables are suitable for indoor use in dry, humid, and very humid environments with high mechanical loads, such as electrical equipment and power tools, especially in low-temperature environments, and are suitable for industrial facilities.
