Conductor: Bare copper multi-strand wire, compliant with IEC60228, EN60228, VDE295, Grade 6
Insulation: TPE510
Color Code: Black cores with consecutive numbering, compliant with EN50334, and a green/yellow ground wire
Core Structure: Layered
Armor: Double-layer non-woven tape
Shielding: Tinned copper braided sleeve
Sheath Material: PU compliant with UL758
Sheath Color: Orange (RAL2003)
Technical Parameters
Rated Voltage: Uo/U 0.6/1kV
Voltage: UL/CSA 1000V
Test Voltage: Core/Shielding 4000V; 2000V
Minimum Bending Radius
Fixed Installation: 5XD
Mobile Installation: 10XD
Continuous Movement: 12XD
Operating Temperature: DIN VDE UL/CSA
Fixed Installation: -50°C to +70°C, up to +80°C
Mobile Installation: -40°C to +70°C, up to +80°C
Flame Retardant Properties: Flame retardant and self-extinguishing, compliant with IEC60332-1-2+EN60332-1-2, CSA FT1+FT2
Radiation Resistance: 5x107cJ/kg
Oil Resistance: Excellent oil resistance at 60°C, compliant with UL1581
Chemical Resistance: Good resistance to acids, alkalis, solvents, hydraulic oils, etc.
Characteristics and Compliance
Characteristics: ◆UL+CSA certified ◆Ultra-high flexibility ◆Excellent electromagnetic performance ◆Oil resistance ◆Ultra-long service life ◆Suitable for drag chains ◆Suitable for DNC motors on frequency converters
Compliance:
Typical Applications
Suitable for fixed installations and flexible use, for machines and industrial factory constructions with general mechanical requirements in dry, humid, and highly humid environments. Also suitable for smart drive industries, including automation technology, power equipment, control and production engineering, processing systems, automotive manufacturing, and high-flex drag chains.
