Conductor: Bare copper multi-stranded wire, compliant with IEC60228, EN60228, VDE0295, Class 5
Insulation: PE L/MD compliant with DIN VDE0819
Color Code: Colors compliant with H308, and one yellow-green grounding wire
Core Structure: Layered
Sheath: PETP foil
Shield: Tinned copper braid
Outer Sheath: Non-woven tape
Sheath Material: Special mixed PVC
Sheath Color: Black (RAL9005)
Technical Parameters
Rated Voltage: Uo/U 0.6/1kV Three-phase and single-phase current: Uo/U 0.7/1.2kV
Maximum Operating Voltage: Operating current: Uo/U 0.9/1.8kV Maximum Alarm Voltage: UΛ1.7kV
Test Voltage: 4000V Cores/Shield 2000V
Minimum Bending Radius: ≤12mm >12mm to ≤20mm >20mm
Fixed Installation: 5×D 7.5×D 10×D
Mobile Installation: 10×D 15×D 20×D
Operating Temperature:
Fixed Installation: -30°C to +70°C
Mobile Installation: -15°C to +70°C
Flame Retardancy: Flame-retardant self-extinguishing compliant with IEC60332-1-2+EN60332-1-2
Radiation Resistance: 8x107cJ/kg
Oil Resistance: Refer to oil resistance table
Chemical Resistance: Refer to chemical resistance table
Characteristics and Compliance
Characteristics: ◆ Low mutual capacitance ◆ Low surface transfer impedance ◆ Excellent electromagnetic performance ◆ Suitable for DIN motors on frequency converters with UΛ1.7kV
Compliance:
Typical Applications
Suitable for fixed installations and flexible use, such as in machines and industrial constructions with general mechanical requirements in dry, wet, and highly humid environments. For example, in automation technology, control and production engineering, robot and industrial plant constructions, motor constructions, drive systems, and power cables between DNC motors in UΛ1.7kV frequency converters and servo motors.
