1. Rotor: The rotor is the central rotating component of the mono pump. It has a single-threaded helical shape that interacts with the stator to create cavities and move the fluid.
2. Stator: The stator is a fixed, typically elastomeric tube or cavity that surrounds the rotor. It forms a tight seal with the rotor and provides a path for the fluid to flow as the rotor rotates.
3. Drive Shaft: The drive shaft connects to the rotor and provides the rotational force necessary for the pumping action. It is usually driven by an electric motor or another power source.
4. Bearings: Bearings support the rotating components of the pump, such as the rotor and drive shaft. They allow for smooth rotation and reduce friction.
5. Casing: The casing encloses the rotor-stator assembly. It provides structural support and protects the internal components of the pump.
6. Inlet and Outlet Ports: The inlet port allows the fluid to enter the pump, while the outlet port is where the pumped fluid is discharged.
7. Seals: Seals are used to prevent leakage between the rotor, stator, and other pump components. They ensure that the fluid flows through the intended path and do not leak outside the pump.
8. Coupling: A coupling connects the drive shaft of the pump to the driving source, such as an electric motor or engine. It transfers the rotational motion from the source to the pump.
9. Motor: The motor provides the power to drive the pump. It can be an electric motor or any other type of motor suitable for the application.
10. Baseplate: The baseplate provides a stable foundation for the pump and helps secure it in place.
It's important to note that the specific design and configuration of a mono pump can vary depending on the manufacturer and the intended application. The parts listed above are common components found in most mono pumps, but there may be additional features and accessories specific to certain models or industries.
